BAER Set HSS: Hexagonal dies: M 3 - 12
BAER Set HSS: Hexagonal dies: M 3 - 12
This tap set is a high quality set for all external thread cutting needs. The metric taps from M3 to M12 allow you to cut external threads.
The set contains hexagonal dies made of HSS steel (High Speed Steel), which ensures long durability and high precision when cutting threads. The thread cutting assortment is supplied in a sturdy plastic box. The cutting nuts are fixed in the box with their own recess.
The tools themselves are characterised by the highest quality. They are optimally processed and guarantee long durability as well as high precision at thread cutting. Whether you are a professional or a do-it-yourselfer, you can cut your external thread effortlessly with this set. Invest in quality and experience the benefits of a professional tap. A tap set that no workshop should be without.
Dimensions
| Diameter |
3 - 12 |
|---|---|
| Dimension |
M 3 - 12 |
Characteristics
| Product group |
threading tool sets |
|---|---|
| Product type |
Threading tool sets |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Direction |
Right |
Technical information - Cutting dies
1,5
ISO-6g
Set content
| BAER HSS hexagonal cutting nuts | M 3 x 0,5 | M 4 x 0,7 | M 5 x 0,8 M 6 x 1,0 | M 8 x 1,25 | M 10 x 1,5 M 12 x 1,75 |
|---|
Applications
- General-purpose use
- Materials with good machinability up to 900 N/mm²
- Unalloyed and low-alloy steels
- for manual use
HSS hexagonal cutting nuts - for perfect external threads
#with corners and edges to the round thread
The hexagonal cutting nut is particularly advantageous for repairs, as it can be moved with ring spanners or open-end spanners, making it easier to reach inaccessible places. BAER hexagonal cutting nuts are taps that are perfect for external threads. This metal-cutting tap has an external hexagon and - depending on the size - has three or more cutting edges on the inside. The holes between the cutting edges take up the chips, roll them and carry them away. Dies are commonly used in everyday life to make screws, nuts and threaded rods. The tap is made of the high-speed steel HSS, which has better toughness and is less susceptible to breakage than HSSE steel. HSS steel is also a popular material for making tools that are subjected to high stresses. HSS cutting nuts can be used for structural steels, carbon steels and free-cutting steels. It is also suitable for case-hardening steels and unalloyed tempering steels with a strength of up to 750 N/mm². Cast steel as well as zinc alloys can also be cut with it, as well as pure copper, low-alloyed copper and short-chipping copper-tin alloys. Also plastics such as POM, PVC etc. It is important that you lubricate the tool plumbed working and with cutting oil or cutting paste.
The advantages at a glance:
- little space required
- Adjustment without effort
- Can be used with ring or open-end spanners
- simple tool assembly
- Use from both sides
Technical information:
- DIN 382
- Thread tolerance: ISO-6g
- Gate: 1,5
HSS hexagon tapping nuts DIN 382 :
M 3 x 0.5 | M 4 x 0.7 | M 5 x 0.8 | M 6 x 1.0 | M 8 x 1.25 | M 10 x 1.5 | M 12 x 1.75
