BAER Set HSSG: Machine Taps | Hexagon Die Nuts: G(BSP) 1/8'' - 3/4''
In stock
Express shipping available
BAER Set HSSG: Machine Taps | Hexagon Die Nuts: G(BSP) 1/8'' - 3/4''
This tap set is a high quality and versatile set for all thread cutting needs in the sanitary sector. The inch taps from G1/8" to G3/4" (also called BSP 1/8" to BSP 3/4") allow you to cut internal and external threads. The G(BSP) thread is also called pipe thread.
The set contains short machine taps made of ground HSS steel (High Speed Steel), which ensure long durability and high precision. Furthermore, HSS hexagonal dies are included in the set so that you can also cut any thread without any problems.
The thread cutting assortment is supplied in a sturdy plastic box. The compartments for the taps provide a secure hold and transport protection and at the same time all the tools are clearly within reach.
The tools themselves are characterised by the highest quality. They are optimally processed and guarantee long durability as well as high precision at thread cutting. In summary, this tap set offers an excellent solution for anyone who wants to cut threads. The combination of high-quality tools and a sturdy plastic box makes it an optimal choice for professionals and DIY enthusiasts alike. Invest in quality and experience the benefits of a professional tap set. A tap set everyone needs in their workshop.
Example applications:- Inch threads or Whitworth threads in the sanitary sector
- G-pipe pipe thread
- Fittings, connectors, nipples, threaded fittings for water pipes, sanitary threads, water threads
- Double nipples and double pipe nipples
- Angle connection
- Pipe threaded connections
Dimensions
| Diameter | 1/8 - 3/4" |
|---|---|
| Dimension | G (BSP) 1/8 - 3/4" |
Characteristics
| Product group | threading tool sets |
|---|---|
| Product type | Threading tool sets |
| Thread standard | G (BSP): British Standard Pipe Thread according to DIN ISO 228 - Cylindrical pipe thread |
| Tolerance | medium |
| Direction | Right |
| Tensile strength at room temperature | up to 900 N/mm² | 27.1 HRC |
| Material | HSSG bright |
Technical information – Screw taps
Through hole and blind hole up to 4 x D
Form D straight fluted
3-4 threads
see illustration
External cooling and lubrication
HSSG bright
up to 900 N/mm² | 27.1 HRC
medium
Technical information - Cutting dies
1,5
A
Set content
| BAER HSSG short machine tap | G 1/8 x 28 | G 1/4 x 19 | G 3/8 x 19 G 1/2 x 14 | G 3/4 x 14 |
|---|---|
| BAER HSSG hexagonal cutting nut | G 1/8 x 28 | G 1/4 x 19 | G 3/8 x 19 G 1/2 x 14 | G 3/4 x 14 |
Applications
- General-purpose use
- Materials with good machinability up to 900 N/mm²
- Unalloyed and low-alloy steels
- for through hole and blind hole
- for manual use
Application – Sample materials for taps
| Unalloyed construction steels | |
|---|---|
| 1.0035 | S185 (St33) |
| 1.0036 | S235JRH |
| 1.0038 | RSt37-2 |
| 1.0039 | S235JRG1+CR |
| 1.0044 | St44-2 |
| 1.0060 | E335 (St60-2) |
| 1.0116 | St37-3 |
| 1.0570 | St 52-3 |
| Alloyed construction steels | |
|---|---|
| 1.5415 | 15Mo3 |
| 1.5423 | 16Mo5 |
| 1.5622 | 14Ni6 |
| 1.7335 | 13CrMo44 |
| 1.7337 | 16CrMo44 |
| 1.7715 | 14MoV63 |
| Free-cutting steels | |
|---|---|
| 1.0711 | 9S20 |
| 1.0715 | 9SMn28 |
| 1.0718 | 11SMnPb30 |
| 1.0721 | 10S20 |
| 1.0723 | 15S20 |
| 1.0726 | 35S20 |
| 1.0737 | 9SMnPb36 |
| 1.0758 | 60SPb20 |
| Case-hardening steels | |
|---|---|
| 1.0401 | (C15) |
| 1.7016 | 17CR3 |
| 1.7131 | 16MnCr5 |
| 1.5919 | 15CrNi6 |
| Quenched and tempered steels unalloyed | |
|---|---|
| 1.0402 | C 22 |
| 1.1151 | C22E (Ck22) |
| 1.0503 | C 45 |
| 1.1191 | C45E (Ck45) |
| Cast steel | |
|---|---|
| 1.0420 | GS-38 |
| 1.5419 | GS-22 Mo 4 |
| 1.6750 | GS-20 NiCrMo3 7 |
| 1.7357 | GS-17 CrMo 5 5 |
| Malleable cast iron | |
|---|---|
| 0.8145 | EN-GJMB 450-6 |
| 0.8170 | EN-GJMB 700-2 |
| 0.8045 | EN-GJMW-450-7 |
| 0.8055 | EN-GJMW-550-4 |
| Pure copper low-alloyed | |
|---|---|
| 2.0240 | CuZn15 |
| 2.0265 | CuZn30 |
| Brass short-chipping | |
|---|---|
| 2.0401 | CuZn39Pb3 |
| Brass long-chipping | |
|---|---|
| 2.0321 | CuZn37 |
| 2.0335 | CuZn36 |
| 2.0360 | CuZn40 |
| Aluminum cast Si > 5-12 % | |
|---|---|
| 3.2161 | G-AlSi8Cu3 |
| 3.2163 | G-AlSi9Cu3 |
| 3.2381 | G-AlSi10Mg |
| 3.2583 | G-AlSi12(Cu) |
| Lamellar graphite cast iron | |
|---|---|
| 0.6010 | EN-GJL 100 (GG-10) |
| 0.6020 | EN-GJL 200 (GG -20) |
| 0.6025 | EN-GJL 250 (GG-25) |
| 0.6030 | EN-GJL 300 (GG -30) |
| Copper-tin alloy (bronze) short-chipping | |
|---|---|
| 2.1090.01 | G-CuSn7ZnPb |
| 2.1086.01 | G-CuSn10Zn |
| 2.1097 | G-CuSn5ZnPb |
| Pure copper, low-alloyed copper | |
|---|---|
| 2.0240 | CuZn15 |
| 2.0265 | CuZn30 |
Further information
- G (BSP) - British Standard Pipe DIN ISO 228 - Cylindrical pipe thread
- Whitworth Pipe Thread
- Information about tapping
- Comparison inch-mm
- Designations, geometries and definitions on taps
- Thread tolerances of the internal thread
- Internal thread and core hole dimensions
- Tap Chamfer forms
- Cutting speeds, lubrication and cooling for taps
- Thread tolerances of external threads
- Bolt pre-machining diameter
Safety instructions
HSS hexagonal die - for perfect external threads
#round runs
BAER dies are used to produce external threads with a round external profile. You want to operate it by hand or by machine? Both work. These BAER dies, made of high-performance high-speed steel HSS, are suitable for normal applications for various materials with a strength of up to 800 N/mm². These include the following materials: general structural steels, free-cutting steels, case-hardening steels, unalloyed heat-treatable steels, pure copper, low-alloyed copper and copper-tin alloy (bronze) short-chipping, as well as plastics. The symmetrical design allows cutting in both axial directions. There are holes on the outside, here you can fix the thread cutting die in the die stock and prevent it from twisting during use. The chip holes, which are holes or cavities between the cutting edges, provide the chip transport. They take up the chips, roll them and carry them away. It is important that you lubricate the tool plumbed working and with cutting oil or cutting paste. Our thread cutting dies for external threads can convince primarily with excellent quality in addition to a fair price. BAER hexagonal tapping nuts - for perfect external threads.
The advantages at a glance:
- low space requirement
- Can also be used in hard-to-reach places
- Can be operated with open-end spanner or open-end spanner
- Use from both sides
Technical information:
- DIN 382
- Gate: 1,5
HSS hexagonal cutting nuts DIN 382 :
G(BSP) 1/8 | G(BSP) 1/4 |G(BSP) 3/8 | G(BSP) 1/2 | G(BSP) 3/4
