Thread ring gauge GO PG 11 x 18 - tolerance Medium
In stock
Thread ring gauge GO PG 11 x 18 - tolerance Medium
BAER's good ring gauges are the perfect testing devices for the so-called mating dimension as well as the screw-on capability of external threads. Due to their high-quality material made of special gauge steel, they are particularly durable and reliable. This means that you can use your ring gauges again and again and rely on a precise result.
Calibration
In the section accessories you can purchase a calibration for your gauge.
Please order the article with article number "KAL01" and the number of gauges you would like to have calibrated.
In the further order process you have the possibility to indicate in the "comment field" which of the ordered gauges you would like to have calibrated.
Dimensions
| Diameter |
11 |
|---|---|
| Pitch |
18 |
| Dimension |
PG 11 x 18 |
Characteristics
| Product group |
Thread gauges |
|---|---|
| Product type |
Thread ring gauges |
| Thread standard |
PG: Armored conduit thread according to DIN 40430 |
| Tolerance |
medium |
| Direction |
Right |
| Material |
Special gauge steel |
