BAER Round Cutting Die M 14 x 2.0 - HSS for Brass
BAER Round Cutting Die M 14 x 2.0 - HSS for Brass
BAER dies are perfect for anyone who wants to cut external threads. Basically, this cutting tool is cylindrical and has - depending on the size - three or more cutting edges inside. The holes between the cutting edges receive the chips, roll them and discharge them. Dies are used to cut screws, nuts and threaded rods in everyday use. The die holder is used to cut the threads by hand and with the special die holders you can also attach the round die to a tailstock or to a drill. The dies can usually be used on both sides and have a perfect cut. Brass is picky when it comes to cutting. When using normal taps, there is a risk of built-up cutting. That is why these BAER external taps are specially designed for brass. The quality tool ensures optimum chip removal with the spiral point (spiral entry) in combination with the lapped and particularly smooth surface. It is important that you lubricate the tool plumbed working and with cutting oil or cutting paste.
Dimensions
| Height H |
14 mm |
|---|---|
| Diameter |
14 |
| Nominal diameter in inches |
0,551 |
| Nominal diameter in mm |
14 |
| Pitch |
2,0 |
| Pitch in mm |
2 |
| Dimension |
M 14 x 2,0 |
Characteristics
| Product group |
Round cutting die |
|---|---|
| Product type |
Round cutting dies |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Tolerance |
ISO-6g |
| Direction |
Right |
| Standard |
DIN 223 (DIN EN 2256 |
| Type |
lapped |
| Material |
HSS |
Technical information - Cutting dies
with spiral entry (spiral point)
1,25
HSS
ISO-6g
Applications
- Brass short-chipping Ms 58
- Brass long-chipping Ms 60
- Examples: CuZn39Pb2; CuZn40Pb2; CuZn20; CuZn37
Technical drawing
| Bolt pre-cutting diameter D2 |
13,82 mm |
|---|---|
| Height H |
14 mm |
| Outside diameter D1 |
38 mm |
| Dimension Diameter D |
M 14 x 2,0 |
| Diameter |
14 |
