BaerCoil Extracting Tool M 11 - M 24 | UNC 3/8 – UNC 1“
EAN
4058462107290
Item no
B7053
PDF offer
Create PDF offer for this product
Tip: Add multiple products to the cart and create the offer there. Logged in users get an individualized offer.
Product information
BaerCoil Extracting Tool M 11 - M 24 | UNC 3/8 – UNC 1“
For quick and easy removal of already installed wire thread inserts from holding threads, the BaerCoil® unscrewing tool is the optimal solution. By pressing the sharp tip firmly into the thread insert, the tool wedges itself in. The thread insert can then be unscrewed effortlessly by turning it anticlockwise. The holding thread is not damaged in the process.
The unscrewing tool can be used for the following dimensions:
- Metric thread inserts: M 11 - M 24
- UNC thread inserts UNC 3/8 - UNC 1"
- UNF thread inserts: UNF 3/8 - UNF 1" & UNF 1" x 14
- BSW thread inserts: BSW 3/8 - BSW 1"
- BSF thread inserts: BSF 3/8 - BSF 1"
- G pipe (BSP) thread inserts: G 1/4 - G 5/8
- BOD thread inserts: BOD 3/8 x 26 - BOD 1/2 x 26
- BSC thread inserts: BSC 3/8 x 26 - BSC 1/2 x 26
- NPT thread inserts: NPT 1/4 x 19 - NPT 1/2 x 14
- Harley thread inserts: Harley 7/16 x 16
- Cummins thread inserts: Cummins 11/16 x 16
- Carburetor thread inserts: Carburetor 7/8 x 20 & Carburetor 1" x 20
Dimensions
| Diameter |
11 - 24 |
|---|---|
| Dimension |
M 11 - 24 |
Characteristics
| Product group |
Wire thread inserts - Assembly tools |
|---|---|
| Product type |
BaerCoil extracting tools |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Direction |
Right |
