BaerCoil Wire Thread Inserts M 10 x 1.0 - 1.0 D (10 mm) - free running - 100 pcs.
BaerCoil Wire Thread Inserts M 10 x 1.0 - 1.0 D (10 mm) - free running - 100 pcs.
BaerCoil® thread inserts are the best solution for your thread repair! With them you can create long-lasting and powerful threaded connections. The inserts also ensure that you have no waste and recycle everything. The inserts are precise and wear resistant - your screw will stay firmly in place without the thread insert slipping.
The BaerCoil® thread insert is the perfect solution for damaged threads while maintaining the same nominal diameter. With BaerCoil® thread inserts, the manufactured thread is significantly stronger than the original thread.
BaerCoil® thread inserts ensure optimum power transmission from the bolt to the nut thread, even in lightweight constructions. Today, they are already an important component in aviation and vehicle construction.
BaerCoil® thread inserts can be shortened according to the required length with a side cutter or similar.
Dimensions
| Diameter |
10 |
|---|---|
| Pitch |
1,0 |
| Dimension |
MF 10 x 1,0 |
| Length |
1,0 D |
| T (Length when installed) |
10 mm |
| Thread length calculation |
1.0 D means 1 times the diameter: 1 times 10 mm=10 mm The nominal diameter for MF 10 is 10 mm |
Characteristics
| Product group |
Wire thread inserts |
|---|---|
| Product type |
BaerCoil wire thread inserts |
| Thread standard |
MF: Metric ISO fine thread according to DIN 13 |
| Tolerance |
ISO2/6H |
| Direction |
Right |
| Type |
free running |
| Tensile strength at room temperature |
>1400 N/mm² |
| Material |
Stainless Steel V2A (AISI 304, X5CrNi18-10, Material No.: 1.4301) |
| Temperature resistance |
315°C long-term 425°C short-term |
Applications
All normal uses for thread repair and thread reinforcement
Technical drawing
| Diameter |
10 |
|---|---|
| Length |
1,0 D |
| T (Length when installed) |
10 mm |
| F (Min. - Max. outside diameter of thread insert) |
11,17 mm - 12,50 mm |
| P (depth) |
The thread insert must sit 1/4 - 1/2 turns below the surface |
| B (thread depth with chamfer) |
13,50 mm |
| D (minimum depth of the core hole, without tip) |
14,50 mm |
