BaerCoil Wire Thread Inserts M 2 x 0.4 - 2.0 D (4 mm) - free running - 100 pcs.
EAN
4058462073625
Item no
1-B7202-2
PDF offer
Create PDF offer for this product
Tip: Add multiple products to the cart and create the offer there. Logged in users get an individualized offer.
Product information
BaerCoil Wire Thread Inserts M 2 x 0.4 - 2.0 D (4 mm) - free running - 100 pcs.
BaerCoil® thread inserts are the perfect solution for your thread repair needs! These inserts provide a long lasting and powerful thread connection and scrap recovery.
The BaerCoil® thread insert is the perfect solution for damaged threads. STI thread (Insert thread) is cut and the BaerCoil® insert is screwed in. The thread produced is significantly stronger than the original thread.
BaerCoil® thread inserts are perfect for applications where a balanced distribution of forces is required. They can withstand both static and dynamic loads and help save support material.
BaerCoil® thread inserts can be shortened with a side cutter or similar, according to the required length.
Dimensions
| Diameter |
2 |
|---|---|
| Pitch |
0,4 |
| Dimension |
M 2 x 0,4 |
| Length |
2,0 D |
| T (Length when installed) |
4 mm |
| Thread length calculation |
2.0 D means 2 times the diameter: 2 times 2 mm=4 mm The nominal diameter for M 2 is 2 mm |
Characteristics
| Product group |
Wire thread inserts |
|---|---|
| Product type |
BaerCoil wire thread inserts |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Tolerance |
ISO2/6H |
| Direction |
Right |
| Type |
free running |
| Tensile strength at room temperature |
>1400 N/mm² |
| Material |
Stainless Steel V2A (AISI 304, X5CrNi18-10, Material No.: 1.4301) |
| Temperature resistance |
315°C long-term 425°C short-term |
Applications
All normal uses for thread repair and thread reinforcement
Technical drawing
| Diameter |
2 |
|---|---|
| Length |
2,0 D |
| T (Length when installed) |
4 mm |
| F (Min. - Max. outside diameter of thread insert) |
2,48 mm - 2,70 mm |
| P (depth) |
The thread insert must sit 1/4 - 1/2 turns below the surface |
| B (thread depth with chamfer) |
5,40 mm |
| D (minimum depth of the core hole, without tip) |
5,80 mm |
