BaerCoil Wire Thread Inserts M 2.5 x 0.45 - 1.0 D (2.5 mm) - free running - 100 pcs.
In stock
Express shipping available
BaerCoil Wire Thread Inserts M 2.5 x 0.45 - 1.0 D (2.5 mm) - free running - 100 pcs.
BaerCoil® thread inserts are the perfect solution for your thread repair needs! These inserts provide a long lasting and powerful thread connection and scrap recovery.
The BaerCoil® thread insert is the perfect solution for damaged threads. STI thread (Insert thread) is cut and the BaerCoil® insert is screwed in. The thread produced is significantly stronger than the original thread.
BaerCoil® thread inserts ensure optimum power transmission from the bolt to the nut thread, even in lightweight constructions. Today, they are already an important component in aviation and vehicle construction.
BaerCoil® thread inserts can be shortened according to the required length with a side cutter or similar.
Dimensions
| Diameter |
2,5 |
|---|---|
| Pitch |
0,45 |
| Dimension |
M 2,5 x 0,45 |
| Length |
1,0 D |
| T (Length when installed) |
2,5 mm |
| Thread length calculation |
1.0 D means 1 times the diameter: 1 times 2.5 mm=2.5 mm The nominal diameter for M 2.5 is 2.5 mm |
Characteristics
| Product group |
Wire thread inserts |
|---|---|
| Product type |
BaerCoil wire thread inserts |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Tolerance |
ISO2/6H |
| Direction |
Right |
| Type |
free running |
| Tensile strength at room temperature |
>1400 N/mm² |
| Material |
Stainless Steel V2A (AISI 304, X5CrNi18-10, Material No.: 1.4301) |
| Temperature resistance |
315°C long-term 425°C short-term |
Applications
All normal uses for thread repair and thread reinforcement
Technical drawing
| Diameter |
2,5 |
|---|---|
| Length |
1,0 D |
| T (Length when installed) |
2,5 mm |
| F (Min. - Max. outside diameter of thread insert) |
3,04 mm - 3,70 mm |
| P (depth) |
The thread insert must sit 1/4 - 1/2 turns below the surface |
| B (thread depth with chamfer) |
4,07 mm |
| D (minimum depth of the core hole, without tip) |
4,52 mm |
