BaerCoil Wire Thread Inserts M 6 x 1.0 - 1.0 D (6 mm) - free running - 100 pcs.
€14.86*
Prices incl. VAT plus shipping costs
In stock
Express shipping is also possible for this product
BaerCoil Wire Thread Inserts M 6 x 1.0 - 1.0 D (6 mm) - free running - 100 pcs.
BaerCoil® thread inserts are the perfect solution for your thread repair needs! These inserts provide a long lasting and powerful thread connection and scrap recovery.
The BaerCoil® thread insert is the perfect solution for damaged threads. With the use of BaerCoil® thread inserts, the thread produced is significantly stronger than the original thread.
BaerCoil® thread inserts ensure that both static and dynamic work loads are evenly distributed between the individual thread turns. Also, the flexibility of the ® thread inserts compensates for any pitch and angular errors, so that optimum force transmission from the bolt to the nut thread is achieved.
BaerCoil® thread inserts can be shortened according to the required length with a side cutter or similar.
Dimensions
| Diameter |
6 |
|---|---|
| Pitch |
1,0 |
| Dimension |
M 6 x 1,0 |
| Length |
1,0 D |
| T (Length when installed) |
6 mm |
| Thread length calculation |
1.0 D means 1 times diameter: 1 times 6 mm=6 mm The nominal diameter for M 6 is 6 mm |
Characteristics
| Product group |
Wire thread inserts |
|---|---|
| Product type |
BaerCoil wire thread inserts |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Tolerance |
ISO2/6H |
| Direction |
Right |
| Type |
free running |
| Tensile strength at room temperature |
>1400 N/mm² |
| Material |
Stainless Steel V2A (AISI 304, X5CrNi18-10, Material No.: 1.4301) |
| Temperature resistance |
315°C long-term 425°C short-term |
Applications
All normal uses for thread repair and thread reinforcement
Technical drawing
| Diameter |
6 |
|---|---|
| Length |
1,0 D |
| T (Length when installed) |
6 mm |
| F (Min. - Max. outside diameter of thread insert) |
7,17 mm - 7,95 mm |
| P (depth) |
The thread insert must sit 1/4 - 1/2 turns below the surface |
| B (thread depth with chamfer) |
9,50 mm |
| D (minimum depth of the core hole, without tip) |
10,50 mm |
