BaerFix Inserting Tool UNC 7/16 x 14
EAN
4058462081897
Item no
1-KEBW24
PDF offer
Create PDF offer for this product
Tip: Add multiple products to the cart and create the offer there. Logged in users get an individualized offer.
Product information
BaerFix Inserting Tool UNC 7/16 x 14
With the BaerFix® installation tool you can easily and efficiently install self-tapping thread inserts in the dimension UNC 7/16 x 14 into your workpiece.
With the 1/4" hexagonal connection, the installation tool can be operated with a cordless screwdriver, ratchet, nut, spanner or handheld screwdriver with bit receptacle.
The thread insert must be screwed onto the insertion tool with the cutting slots or cutting holes pointing downwards and tightened with the nuts. The nuts can be tightened and loosened with an 11/16'' spanner. The BaerFix threaded insert can then be easily turned into the locating hole. Once the threaded insert is installed, the lock nuts must be loosened and the installation tool unscrewed again.
Dimensions
| Diameter |
7/16 |
|---|---|
| Pitch |
14 |
| Dimension |
UNC 7/16 x 14 |
| Length |
87 mm |
Characteristics
| Product group |
Self-cutting thread inserts - Assembly tools |
|---|---|
| Product type |
BaerFix installation tools |
| Thread standard |
UNC: American Unified National Coarse thread according to ANSI B1.1 |
| Direction |
Right |
