BaerFix Inserting Tool UNF 1/2 x 20
With the BaerFix® installation tool you can easily and efficiently install self-tapping thread inserts in the dimension UNF 1/2 x 20 into your workpiece.
With the 10 mm hexagonal connection, the installation tool can be operated with a ratchet, nut, spanner or open-end spanner.
The thread insert must be screwed onto the insertion tool with cutting slots or cutting holes facing downwards and tightened with the nuts. The nuts can be tightened and loosened with a 3/4" spanner. The BaerFix threaded insert can then be easily turned into the locating hole. Once the threaded insert is installed, the lock nuts must be loosened and the installation tool unscrewed again.
Dimensions
| Diameter |
1/2 |
|---|---|
| Pitch |
20 |
| Dimension |
UNF 1/2 x 20 |
| Length |
117 mm |
Characteristics
| Product group |
Self-cutting thread inserts - Assembly tools |
|---|---|
| Product type |
BaerFix installation tools |
| Thread standard |
UNF: American Fine Unified National thread according to ANSI B1.1 |
| Direction |
Right |
