BaerCoil Wire Thread Inserts M 4 x 0.7 - 1.0 D (4 mm) - free running - AISI 316 - 100 pcs.
BaerCoil® thread inserts are the perfect solution for your thread repair needs! These inserts provide a durable and powerful thread connection and scrap recovery.
The BaerCoil® thread insert is the perfect solution for damaged threads - with the same nominal diameter! For thread repair with wire thread inserts, the thread is drilled out and a new STI thread (screw thread insert) for the wire thread insert is cut. This thread is often also called STI thread (STI=Screw Thread Insert).
BaerCoil® thread inserts are essential for optimal power transmission in lightweight constructions. They ensure that both static and dynamic work loads are distributed in a balanced manner to the individual thread turns. Also, the flexibility of the thread inserts compensates for any pitch and angle errors. BaerCoil® thread inserts not only save time and money, but are also much lighter and more compact than conventional screw connections.
BaerCoil® thread inserts can be shortened, according to the required length, with a side cutter or similar.
Dimensions
| Diameter |
4 |
|---|---|
| Pitch |
0,7 |
| Dimension |
M 4 x 0,7 |
| Length |
1,0 D |
| T (Length when installed) |
4 mm |
| Thread length calculation |
1.0 D means 1 times the diameter: 1 times 4 mm=4 mm The nominal diameter for M 4 is 4 mm |
Characteristics
| Product group |
Wire thread inserts |
|---|---|
| Product type |
BaerCoil wire thread inserts |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Tolerance |
ISO2/6H |
| Direction |
Right |
| Type |
free running |
| Tensile strength at room temperature |
>1400 N/mm² |
| Material |
Stainless Steel V4A (AISI 316, X5CrNiMo17-12-2, Material No.: 1.4401) |
| Temperature resistance |
315°C long-term 425°C short-term |
Applications
Applications in seawater and chlorinated water
Attributes
- improved corrosion resistance
- reduced thread friction
- for high-alloy CrNi steel screws
Technical drawing
| Diameter |
4 |
|---|---|
| Length |
1,0 D |
| T (Length when installed) |
4 mm |
| F (Min. - Max. outside diameter of thread insert) |
4,83 mm - 5,60 mm |
| P (depth) |
The thread insert must sit 1/4 - 1/2 turns below the surface |
| B (thread depth with chamfer) |
6,45 mm |
| D (minimum depth of the core hole, without tip) |
7,15 mm |
