BaerCoil Wire Thread Inserts UNF 1/2 x 20 - 1.5 D (19.05 mm) - free running - 100 pcs.
In stock
Express shipping available
BaerCoil Wire Thread Inserts UNF 1/2 x 20 - 1.5 D (19.05 mm) - free running - 100 pcs.
BaerCoil® wire thread inserts are the perfect solution for a long-lasting, powerful thread connection and scrap recovery. They also create load-bearing connections in materials with low shear strength and are precise and wear-resistant. wire thread inserts are often used in automotive, electrical engineering, medical technology, lightweight construction and aerospace.
The BaerCoil® thread insert is the perfect solution for damaged threads and that at the same time nominal diameter. With BaerCoil® thread inserts, the thread produced is significantly more stable than the original thread.
BaerCoil® thread inserts are indispensable for optimal power transmission in lightweight constructions. They ensure that both static and dynamic work loads are distributed in a balanced manner to the individual thread turns. Also, the flexibility of the thread inserts compensates for any pitch and angle errors. BaerCoil® thread inserts not only save time and costs, but are also much lighter and more compact than conventional screw connections.
BaerCoil® thread inserts can be shortened, according to the required length, with a side cutter or similar.
Dimensions
| Diameter |
1/2 |
|---|---|
| Pitch |
20 |
| Dimension |
UNF 1/2 x 20 |
| Length |
1,5 D |
| T (Length when installed) |
19,05 mm |
| Thread length calculation |
1.5 D means 1.5 times the diameter: 1.5 times 12.7 mm=19.05 mm The nominal diameter for UNF 1/2 is approx. 12.7 mm |
Characteristics
| Product group |
Wire thread inserts |
|---|---|
| Product type |
BaerCoil wire thread inserts |
| Thread standard |
UNF: American Fine Unified National thread according to ANSI B1.1 |
| Direction |
Right |
| Type |
free running |
| Tensile strength at room temperature |
>1400 N/mm² |
| Material |
Stainless Steel V2A (AISI 304, X5CrNi18-10, Material No.: 1.4301) |
| Temperature resistance |
315°C long-term 425°C short-term |
Applications
All normal uses for thread repair and thread reinforcement
Technical drawing
| Diameter |
1/2 |
|---|---|
| Length |
1,5 D |
| T (Length when installed) |
19,05 mm |
| F (Min. - Max. outside diameter of thread insert) |
0,559 '' - 0,617 '' |
| P (depth) |
The thread insert must sit 1/4 - 1/2 turns below the surface |
| B (thread depth with chamfer) |
0,925 '' |
| D (minimum depth of the core hole, without tip) |
0,975 '' |
