Thread Plug Gauge M 14 x 2.0 - tolerance 6H
In stock
Thread Plug Gauge M 14 x 2.0 - tolerance 6H
The BAER limit plug gauge is a unique testing device that allows you to test internal thread with a single gauge. The GO side of the plug gauge has a full thread profile that must be able to be turned fully into the thread by hand when testing. The reject side is different - it has a shortened thread profile. If it can be screwed in further than two turns, the cut thread is not in order. This unique function of the BAER limit plug gauge guarantees the highest precision and quality in the production of internal threads. The thread to be tested must be clean and free of lubricant residues. To achieve an accurate test result, make sure that the thread to be tested is clean and free of lubricant residues. The ambient temperature and the temperature of the component should be at 20 degrees. Otherwise, the test result may be falsified.
Calibration
In the section accessories you can purchase a calibration for your gauge.
Please order the article with article number "KAL01" and the number of gauges you would like to have calibrated.
In the further order process you have the possibility to indicate in the "comment field" which of the ordered gauges you would like to have calibrated.
Dimensions
| Diameter |
14 |
|---|---|
| Pitch |
2,0 |
| Dimension |
M 14 x 2,0 |
Characteristics
| Product group |
Thread gauges |
|---|---|
| Product type |
Thread plug gauges |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Tolerance |
ISO2/6H |
| Direction |
Right |
| Material |
Special gauge steel |
