Thread Plug Gauge M 18 x 2.5 - tolerance 6H
In stock
Thread Plug Gauge M 18 x 2.5 - tolerance 6H
The thread limit plug gauge combines the thread Go gauge plug and the thread NO-GO gauge plug. This allows you to test internal thread with a single gauge. The GO side has a complete thread profile that must be able to be turned completely into the thread by hand when testing. The scrap side is different - it has a shortened thread profile. If it can be screwed in further than two turns, the cut thread is not OK. To achieve an accurate test result, you should ensure that the thread to be tested is clean and free of lubricant residue. The ambient temperature and the temperature of the component should both be 20 degrees. Otherwise, the test result may be falsified.
Calibration
In the section accessories you can purchase a calibration for your gauge.
Please order the article with article number "KAL01" and the number of gauges you would like to have calibrated.
In the further order process you have the possibility to indicate in the "comment field" which of the ordered gauges you would like to have calibrated.
Dimensions
| Diameter |
18 |
|---|---|
| Pitch |
2,5 |
| Dimension |
M 18 x 2,5 |
Characteristics
| Product group |
Thread gauges |
|---|---|
| Product type |
Thread plug gauges |
| Thread standard |
M: Metric ISO standard thread according to DIN 13 |
| Tolerance |
ISO2/6H |
| Direction |
Right |
| Material |
Special gauge steel |
