Thread plug gauge NPT 1'' x 11.5 - tolerance Medium

€258.65*

Prices incl. VAT plus shipping costs

In stock

EAN 4058462128660
Item no 242101009
PDF offer
Create PDF offer for this product Tip: Add multiple products to the cart and create the offer there. Logged in users get an individualized offer.
Product information

Thread plug gauge NPT 1'' x 11.5 - tolerance Medium


In contrast to cylindrical thread limit plug gauges, tapered thread limit plug gauges have a measuring stage and thus test the thread minimum dimension and the thread maximum dimension. When thread testing with a tapered thread limit plug gauge, it must be possible to screw in the thread gauge between the first and second stage. To obtain an accurate test result, ensure that the thread to be tested is clean and free of lubricant residue. The ambient temperature and the temperature of the component should both be 20 degrees. Otherwise, the test result may be falsified.


Calibration

In the section accessories you can purchase a calibration for your gauge.
Please order the article with article number "KAL01" and the number of gauges you would like to have calibrated.
In the further order process you have the possibility to indicate in the "comment field" which of the ordered gauges you would like to have calibrated.

Dimensions

Diameter 1"
Pitch 11,5
Dimension NPT 1" x 11,5

Characteristics

Product group Thread gauges
Product type Thread plug gauges
Thread standard NPT: National Pipe Thread or American pipe thread according to ANSI B 1.20.1
Tolerance medium
Direction Right
Material Special gauge steel

Accessories

Zubehör
